- Compact yet wide-range extraction capacity
- Koike’s Oil Skimmers efficiently extract floating oil, scum and sludge from the coolant fluids and prevents the saprogenic bad odor, making them the industry standard for compact oil skimmers. Koike’s Oil Skimmers are optionally adopted by different equipment manufacturers.
FEATURE
Key features of Oil Skimmer type JS25
-
- Advanced belt specifications
- The special seamless belt (25mm) with outstanding lipophilic properties is used. Floating oil is efficiently collected and the product durability is excellent as well.
- 01
-
- DURACON rollers adopted
- The rollers made of DURACON eliminate the rusting problems and the improvements including the weight reduction helped increase the durability.
- 02
-
- Compact design
- With more freedom in the space to install, the Skimmer can be easily fastened with two bolts.
- 03
-
- CE-compliant motor (standard)
- The motor can be made compliant to different standards, including UL and CCC.
- 04
-
- Aluminum terminal box standardized
- Replaced from the plastic box, the aluminum terminal box has reduced the breakage risk.
- 05
-
- Newly added inspection window
- Setting up an inspection window realized a structure for easier operation monitoring from the outside.
- 06
DOWNLOAD
Drawings and brochures download
- Koike Oil Skimmer, type JS25
（KOIKE OIL SKIMMER) - Click the button below to view the material. Adobe Acrobat Reader is required to view pdf files. Adobe Acrobat Reader is available for free from Adobe. Click here to download the free Reader.
- DOWNLOAD
SPEC
Specifications
- Details
-
Electrical specification 200V 3-phase, 15W, 0.13A rated amperage Collection capacity Type SOC: 6 L/h (user equipment measurement) Belt width Type SOC: 25mm Note: An oil-water separation tank is available as an option.
- Type JS25
-
Product code A dimension Belt length JS25-115E 115mm 800mm JS25-200E 200mm 970mm JS25-300E 300mm 1170mm Product code JS25-115E JS25-200E JS25-300E A dimension 115mm 200mm 300mm Belt length 800mm 970mm 1170mm Note: 200V/220V 50/60HZ．15W 4P 1/50 Rated amperage: 0.13A
For coolants Vertical type Plastic belt JS25-115E Plastic belt JS25-200E Plastic belt JS25-300E For coolants Plastic belt Plastic belt Plastic belt Vertical type JS25-115E JS25-200E JS25-300E
- Product code convention
